Silicon Chip April 2013

In this issue of Silicon Chip Electronics Magazine, the third installment of building the High-Performance Stereo Digital-to-Analog Converter. These units are ideal to convert your MP3 or digital music to high quality stereo for your headphones or input to your sound system. This unit is based on the Cirrus Logic CS4398, as used in Marantz and other high-fidelity sound equipment. It has three TOSLINK inputs, three S/PDIF inputs and a USB audio input. A SD card socket is also included. The unit also incorporates a headphone amplifier and an optional infrared remove control. The unit can be built in a few hours and delivers exceptional sound quality.

Also this month, build an attractive eye-catching LED Ladybird. This compact, easy to build brooch, features simulated body movements and wings flapping using an array of LEDs. The unit is great for parties and is sure to attract pleny of attention. Finally this month, a Deluxe GPS 1pps Timebase for Frequency Counters, this unit provides a very accurate timebase ensuring accurate readings for frequency measing instruments. All projects come complete with circuit diagram and electronic parts list.

This month’s articles include a look at receiving Digital TV on your laptop. Access a wide range of programming and news broadcast directly on your PC, with this inexpensive USB dongle for your PC or laptop.

Part Code: SILCHIPAPR2013

Features

How to Get Digital TV on your Laptop or PC
The New Silicon Chip Website
Review: Siglent SDG1050 50MHz 2-Channel Function Generator

Projects

High Performance CLASSiC DAC, Part 3
LED Ladybird: An Eye-Catching Electronic Beetle
Deluxe GPS 1pps Timebase for Frequency Counters
A Rugged 10A Battery Charger from Bits & Pieces
