TI Release 200-W and 100-W USB Type-C™ Power Delivery Controllers


New controllers enable higher power in dual- and single-port applications


Texas Instruments has introduced two new USB Type-C™ and USB Power Delivery (PD) controllers, with fully integrated power paths to simplify designs, minimize solution size and speed time to market. The TPS65987D and TPS65988 offer system designers the industry’s highest level of integration which can reduce design complexity and overall cost.

Click for Larger Image - TI Release 200-W and 100-W USB Type-C USB Power Delivery Controllers The devices are the industry’s first USB PD controllers to source 100 W and 200 W of power, respectively, to support computing applications and enable the benefits of USB Type-C in additional applications such as cordless power tools, gaming and virtual reality headsets. The TPS65987D, a single-port device designed to source 100 W of power, integrates independent 20-V, 5-A source and sink load switches. Low RDS(on) (25 mΩ) and reverse current protection in the TPS65987D provide a comprehensive solution for managing a port’s charging needs. The dual-port TPS65988 can source 200 W of power, and offers two integrated 5-A bidirectional load switches and external power-path control to enable simultaneous 5-A source capability.

The devices are USB PD 3.0-certified, UL Recognized, and International Electrotechnical Commission (IEC) safety-certified, and come preprogrammed to support several of the most common use cases including DisplayPort™ and Thunderbolt™ applications. Additional use cases are supported through an easy-to-use configuration tool.

Key features and benefits of the TPS65987D and TPS65988:

  • Fewer components, simpler designs: Fully integrated USB PD controllers can help designers reduce design complexity, compared to discrete implementations which typically require 18 external power-path components. In addition, the new controllers offer integrated reverse current protection for multiple power paths, to further save board space and protect the system and controller from overcurrent.
  • Industry’s highest power level: 200 W of power allows fast USB Type-C charging, with two integrated 5-A field-effect transistor (FET) paths to enable high-power applications such as PC notebooks, docking stations or connected peripherals while maintaining low RDS(on) for efficient charging with minimal power loss.
  • Easily configured: No firmware development is necessary, as each device is pre-configured for the most common use cases - enabling quick and easy selection and implementation.

More information on the TPS65988 Dual Port USB Type-C Controller, can be found on the TI Web site at TI TPS65988 product page

Information on the TPS65987D USB Type-C and USB PD Controller, can be found at TI TPS65987D product page

The company's Web site address is www.ti.com
[Reprinted with kind permission from Texas Instruments - Release Date, 18th September, 2018]
