New CAN chip from TI With Integrated CAN FD Controller and Transceiver


This system basis chip allows CAN FD to be easily added to a microcontroller and automotive network


Texas Instruments have introduced an automotive system basis chip that is the industry’s first to integrate a controller and transceiver for Controller Area Network with Flexible Data Rate (CAN FD). Designed to meet the high-bandwidth and data-rate flexibility needs of in-vehicle networks, the TCAN4550-Q1 uses the Serial Peripheral Interface (SPI) bus of most microcontrollers to implement, with minimal hardware changes, a CAN FD interface or increase the amount of CAN FD bus ports in a system.

Click for Larger Image - New Automotive LED Lighting Controller from Texas Instruments Previously, designers had to incorporate a nummber of discrete components into their designs or change microcontrollers entirely when upgrading to or expanding CAN FD functionality – an often time-consuming and expensive process. With the TCAN4550-Q1 system basis chip (SBC), designers can maintain their existing microcontroller-based architecture and incorporate the CAN FD upgrade or expansion in body electronics and lighting, advanced driver assistance systems (ADAS) and automotive gateway designs.

The CAN FD communications protocol builds on the original CAN bus standard (also known as "Classical CAN") to help ensure that automotive microcontrollers and connected systems can communicate effectively as the variety and speed of data rates throughout in-vehicle networks continue to increase and evolve. With support for data rates up to 5 Mbps and payloads up to 64 bytes, the CAN FD protocol empowers designers to move data quicker in their next-generation automotive applications.

Key features and benefits of TI’s TCAN4550-Q1:

  • Reduced bill of materials (BOM) and system costs: Designers can simplify their designs with the high integration of the TCAN4550-Q1 – including integrated ±58-VDC bus fault protection, watchdog timer and fail-safe modes – and its cross-compatibility with the Classical CAN protocol.
  • Easier bus expansion in automotive designs: Designers can also use the chip to add more CAN FD buses via the existing SPI port in an automotive system when the microcontroller has a limited number of CAN FD ports. Typically this type of bus expansion can require system redesign, which is not necessary when using the TCAN4550-Q1.
  • Small power design footprint: With an integrated 125-mA low-dropout (LDO) linear regulator, the TCAN4550-Q1 can power itself while also providing a 70-mA external output that can be used to power sensors or additional components, which enables a smaller power design footprint by reducing the need for external power components.
  • Reduced power consumption: The TCAN4550-Q1 helps designers lower system power consumption when in standby mode through wake and inhibit features.
  • Increased maximum data rate: The new SBC enables faster programmability of automotive software during vehicle assembly through a maximum data rate of 8 Mbps, which exceeds the 5-Mbps maximum data rate of the CAN FD protocol.

For more information on the TCAN4550-Q1 Automotive system basis chip, visit the TI website at TI TCAN4550-Q1 System Chip main page


The company's Web site address is www.ti.com
[Reprinted with kind permission from Texas Instruments - Release Date, 11th June, 2019]
