ST Releases Three-Phase Half-Bridge Driver IC for Low Voltage Applications


The STDRIVE101 delivers a space-efficient and power-saving solution to control three-phase brushless motors


STMicroelectronics has created an integrated three-phase half-bridge driver IC with performance optimized for low-voltage industrial applications up to 75V, delivering a space-efficient and power-saving solution to control three-phase brushless motors in e-bikes, power tools, pumps, fans, light machinery, gaming consoles, and other equipment.

Click for Larger Image - ST Releases Three-Phase Half-Bridge Driver IC for Low Voltage Applications The STDRIVE101 embeds three half-bridge drivers for external N-Channel MOSFETs, each able to sink and source up to 600mA gate current. Integrated bootstrap diodes and a 50mA 12V low-dropout (LDO) regulator ready to supply external components help designers minimize the bill of materials. A comparator for over-current detection using external resistors and drain-source voltage monitoring of each MOSFET for short-circuit protection are also provided.

Essential safety features are built-in, including internally generated dead-time to prevent cross-conduction, over-temperature shutdown, and Under-Voltage Lockout (UVLO) on both the low-side and high-side sections to prevent the MOSFETs from operating in low efficiency or dangerous conditions.

A DT/MODE selection pin lets designers choose to control switching with individual high-side and low-side signals or a single PWM signal and enable input. A standby pin sets the STDRIVE101 in low-power mode with the LDO turned off to maximize energy savings when idle.

Features of the STDRIVE101 Low Voltage Gate Driver include:

  • Operating voltage from 5.5 to 75 V
  • 600 mA sink/source current capability
  • 3.3 V and 5 V control logic
  • Two input strategies:
    • ENx/INx with adjustable deadtime generation
    • INHx/INLx with interlocking
  • Matched propagation delay for all channels
  • Very short propagation delay: 40 ns
  • Integrated bootstrap diodes
  • 12 V LDO linear regulator (50 mA max.)
  • Embedded VDS monitor for each external MOSFET
  • Overcurrent comparator
  • UVLO and thermal shutdown protection
  • Standby mode for low current consumption operation

More information on the STDRIVE101 Low Voltage Gate Driver is available on the ST Web site at STMicroelectronics STDRIVE101 product page.


The company's Web site address is www.st.com.
[Reprinted with kind permission from STMicroelectronics - Release Date, 7th December, 2020]
