New PIC Micros with Hardware ADC Computation and 16-bit PWM's

Microchip's new Microcontrollers also offer Low-Power Modes and Peripheral Pin Select

Microchip has just released two new 8-bit families that expand its growing portfolio of innovative PIC® MCUs with Core-Independent Peripherals (CIPs). 8-bit MCUs can now be used in a much broader range of applications, due to the growing number of these intelligent, interconnected CIPs that combine to perform functions autonomously, without the core. Because these functions are deterministically and reliably performed in hardware instead of software, CIPs enable system performance that is far beyond typical 8-bit MCUs while simplifying the design experience and reducing memory cost. Additionally, these two new families are available in 8 to 40-pin packages, reducing board space while serving a wide 1.8 to 5.5V operating range. Both families offer the Peripheral Pin Select feature, which enables flexible pin mapping and PCB routing to minimize EMI and crosstalk. Example applications include consumer electronics, the Internet of Things (IoT), wearable technology and safety-critical systems.

The four new members of the PIC16F1579 Family are offered in 14 to 20-pin packages with up to 28 KB of Flash and feature CIPs that enable functions in a broad range of applications, such as LED lighting and motor control. They are the first 8-bit PIC MCUs with four 16-bit PWMs that each have independent timers, for flexible output and signal generation functions, including edge, center-aligned and other output modes. System-communication functions are supported via serial interfaces for LIN and DMX connectivity, while the family's intelligent analog integration enables signal and sensor interface functions.

The first 10 members of the PIC16F18877 Family are available in 8 to 40-pin packages with up to 56 KB of Flash and feature CIPs that enable functions in a broad range of applications, such as consumer electronics, IoT and safety-critical systems. They are the first MCUs to integrate an ADC with computation, which performs input and sensor interface functions such as accumulation, averaging and low-pass filter calculations in hardware instead of software, enabling the CPU to Sleep or execute other tasks. They're also the first PIC16 MCUs to augment Microchip's eXtreme Low Power (XLP) technology with the IDLE and DOZE modes for reduced active power consumption. Additionally, they're the first 8-bit MCUs with Peripheral Module Disable, which completely removes peripherals from the power rail and clock tree for zero power leakage. Other integrated CIPs, such as the Hardware Limit Timer, combine for the easy implementation of safety-critical functions.

“These two new families are the latest examples of Microchip’s leadership in the 8-bit MCU market, with the continued expansion of innovative CIPs and intelligent analog that enable functions and capabilities far beyond what traditional 8-bit MCUs could perform,” said Steve Drehobl, vice president of Microchip's MCU8 Division. “These families also exemplify Microchip’s ‘Flexible Intelligence Made Easy’ philosophy, as they provide designers with a broad range of intelligent and configurable peripheral options in many low pin count packages and a wide operating voltage range. Development is made easy via our comprehensive platform of software and hardware tools, integrated under our singular MPLAB®X IDE.”

Features of the PIC16F18877 Microcontroller

More information on the PIC16F1579 Microcontrollers can be found on the Microchip website at www.microchip.com/en-us/product/PIC16F1579

More information on the PIC16F18877 Microcontrollers can be found on the Microchip website at www.microchip.com/en-us/product/PIC16F18877

Note: The Microchip name and the Microchip logo are registered trademarks of Microchip Technology Incorporated in the U.S.A and other countries. All other trademarks mentioned herein are the property of their respective companies.

The Microchip website address is www.microchip.com
[Reprinted with kind permission from Microchip Corporation - Release Date, 20th July, 2015]
